Using Telephony on Macintosh Computers (IM: Telephony)

Inside Macintosh: Telephony /: Chapter 1 - Introduction to Telephony on the Macintosh

Using Telephony on Macintosh Computers
This section describes the steps you need to perform before you can use the Telephone Manager to open and configure telephone terminals, manage directory numbers, or create and manage call appearances. It shows how to

determine whether the Telephone Manager is available in the current operating environment
initialize the Telephone Manager
find and configure a telephone tool
create a telephone record
open a telephone terminal

See Chapter 4, "Call Appearances," for a complete code sample for initializing the Telephone Manager and placing a telephone call.

Determining if the Telephone Manager Is Available
Before calling any Telephone Manager routines, you need to verify that the Telephone Manager is available in the current operating environment and that it has the capabilities you need. You can verify that the Telephone Manager is available by calling the Gestalt function with the gestaltTeleMgrAttr selector. Gestalt returns, in its second parameter, a long word whose value encodes the attributes of the Telephone Manager. Listing 1-1 illustrates how to determine whether the Telephone Manager is available.
Listing 1-1 Checking for the availability of the Telephone Manager
Boolean MyHasTelephoneManager (void)
{
   OSErr       myErr;
   long        myAttrs;
   Boolean     myHasTelMgr = false;

   myErr = Gestalt(gestaltTeleMgrAttr, &myAttrs);
   if (myErr == noErr)
      if (myAttrs & (1 << gestaltTeleMgrPresent))
         myHasTelMgr = true;

   return(myHasTelMgr);
}
Note
For more information on the Gestalt function, see Inside Macintosh: Operating System Utilities.
You can also use the Gestalt function to get information about other attributes of the Telephone Manager. For example, you can determine whether the available version of the Telephone Manager supports the TELNewWithResult function. See "Gestalt Selector and Response Values" on page 1-21 for complete details on the Telephone Manager attributes you can query.

Note
To determine the available version of the Telephone Manager, use the TELGetTELVersion function. See page 1-30 for details.

Initializing the Telephone Manager
Once you've determined that the Telephone Manager is available in the current operating environment, you need to initialize the Communications Toolbox and the Telephone Manager itself. You can use the function MyInitCTBManagers defined in Listing 1-2 to perform this initialization.
Listing 1-2 Initializing the Communications Toolbox and Telephone Manager
OSErr MyInitCTBManagers (void)
{
   OSErr    myErr = noErr;

   myErr = InitCRM();   //initialize Comm'ns Resource Manager
   if (myErr == noErr) {//initialize CTB Utilities
      myErr = InitCTBUtilities();
      if (myErr == noErr)
         myErr = InitTEL();//initialize Telephone Manager
   }

   return(myErr);
}
The function MyInitCTBManagers calls InitCRM and InitCTBUtilities to initialize the Communications Resource Manager and the Communications Toolbox Utilities. Then, if both these calls succeed, MyInitCTBManagers calls InitTEL to initialize the Telephone Manager. If MyInitCTBManagers returns noErr, you can proceed to find and configure any telephone tools your application needs to use.

Finding Telephone Tools
Before your application can use the services of the Telephone Manager (for instance, to place outgoing calls or receive incoming calls), it needs to open a telephone terminal and configure the telephone tool associated with that terminal. The tool translates the network-independent routines called by your application into network-specific protocols used by the telephone terminal. As you've seen, a Macintosh computer might be connected to several different types of telephone networks (ISDN, POTS, and so forth). As a result, your application needs to select, from among all available tools, the one that provides the services you need to use.
In practice, it's likely that any available tool will be able to provide the telephony services you need. (Indeed, it's possible that a particular Macintosh computer supports only one telephone terminal and hence one telephone tool.) Nonetheless, your application should be prepared to look for all telephone tools available in the current operating environment and select one. Listing 1-3 illustrates one way to select a telephone tool. The function MyGetFirstTelTool returns the tool ID of the first available telephone tool. A tool ID is an integer that uniquely identifies a telephone tool.

WARNING
Tool IDs are assigned to tools dynamically at run time, so you should not store them in files.<8batcolor>s
Listing 1-3 Finding a telephone tool
short MyGetFirstTelTool (void)
{
   OSErr    myErr = noErr;
   short    myIndex;
   short    myID = -1;
   Str255   myName;

   for (myIndex = 1; myID == -1; myIndex++) {
      myErr = CRMGetIndToolName(classTEL, myIndex, myName);
      if (myErr != noErr)
         break;
      if (*myName == nil)
         break;
      myID = TELGetProcID(myName);
   }

   return(myID);
}
The MyGetFirstTelTool function defined in Listing 1-3 calls the Communications Resource Manager function CRMGetIndToolName to get the name of a telephone tool. Telephone tools are contained in files of type classTEL:
enum {
   classTEL                = 'vbnd'
};
If CRMGetIndToolName completes successfully and returns a non-empty name, then MyGetFirstTelTool calls TELGetProcID to get the tool ID of that tool, which it returns as its function result. You'll need this tool ID to create a new telephone record and configure the telephone tool, as described in the following two sections.

Note
There are other ways to get the name of a telephone tool. For instance, you could save the name of the current tool in a preferences file associated with your application. Then, when your application starts up, it can read the name from that file.

Creating Telephone Records
The Telephone Manager stores information about a particular telephone terminal and its associated telephone tool in a telephone record, a data structure of type TELRecord:
struct TELRecord {
   short                   procID;
   TELFlags                flags;
   short                   reserved;
   long                    refCon;
   long                    userData;
   UniversalProcPtr        defproc;
   Ptr                     config;
   Ptr                     oldConfig;
   TELTermPtr              pTELTerm;
   long                    telPrivate;
   long                    reserved1;
   long                    reserved2;
   long                    pTELTermSize;
   short                   version;
};
typedef struct TELRecord TELRecord;
typedef TELRecord *TELPtr, **TELHandle;
You need to call either TELNew or TELNewWithResult to create a telephone record, which you can then configure with information about the desired terminal and tool. Calling TELNewWithResult is the preferred method of creating a telephone record, because it returns information about any errors that occur in the process of creating the new record. However, the TELNewWithResult function is not available in all versions of the Telephone Manager. Accordingly, you need to determine that TELNewWithResult is available before you call it. Listing 1-4 illustrates how to create a new telephone record.
Listing 1-4 Creating a telephone record
TELHandle MyGetTelRecord (short myID)
{
   OSErr    myErr = noErr;
   TELErr   myTelErr;
   long     myAttrs;
   TELHandlemyTerm;

   if (myID == -1)
      return(nil);

   myErr = Gestalt(gestaltTeleMgrAttr, &myAttrs);
   if (!myErr)
      if (myAttrs & (1 << gestaltTeleMgrNewTELNewSupport)) {
         myTerm = TELNewWithResult(myID, 0, 0, 0, &myTelErr);
      } else {
         myTerm = TELNew(myID, 0, 0, 0);
      }

   return(myTerm);
}
The MyGetTelRecord function defined in Listing 1-4 requires a tool ID as a parameter. It calls the Gestalt function to determine whether the TELNewWithResult function is available. If it is, MyGetTelRecord calls TELNewWithResult to create a new telephone record; otherwise, MyGetTelRecord calls TELNew to create a new telephone record.
The TELNewWithResult and TELNew functions fill in as much of the returned telephone record as possible, based on the information passed in. The specified telephone tool also fills in the fields of the telephone terminal record pointed to by the pTELTerm field of the telephone record. See "Telephone Terminal Record" on page 2-16 for complete details about the telephone terminal record.

Configuring Telephone Tools
Once you've found a telephone tool and created a telephone record describing it, the final step in preparing your application to work with the Telephone Manager is to configure the telephone tool by filling in the configuration information (contained in the config and oldConfig fields) and verifying that all the fields in the record are valid.
There are three basic ways in which you can configure a telephone tool. The simplest way is to call the TELChoose function, which displays to the user a standard tool-settings dialog box (Figure 1-3). The dialog box provides controls that allow the user to select the appropriate telephone tool and the desired options.
Figure 1-3 The standard tool-selection dialog box

The TELChoose function automatically updates the necessary telephone records, fills in the configuration information and ensures that all the fields are valid. Listing 1-5 illustrates how to call TELChoose.
Listing 1-5 Configuring a telephone tool using TELChoose
TELHandle MyConfigTelTool (TELHandle myTelRec)
{
   OSErr    myErr = noErr;
   Point    myPoint;

   if (myTelRec == nil)
      return(nil);

   myPoint.v = 80;
   myPoint.h = 80;
   myErr = TELChoose(&myTelRec, myPoint, nil);

   return(myTelRec);
}
It's possible for the user to select a new telephone tool in the tool-settings dialog box displayed by TELChoose. If the user does select a new tool, TELChoose disposes of the handle you passed in and creates a new one. In Listing 1-5, the existing or new handle is returned to the caller as the function result.
The second way to configure a telephone tool is to display a custom tool-setting dialog box. This method is more complicated than using TELChoose, and requires you to call six separate functions to display and handle the dialog box. See "Configuring a Telephone Tool Through a Custom Interface," beginning on page 1-39 for complete details on these functions.
Finally, you can configure a telephone tool without any user intervention at all by calling the TELSetConfig function, which passes a configuration string to a telephone tool. This string might have been stored in a file or passed to your application from some other application using Apple events. (You can get a configuration string from a tool by calling TELGetConfig.) See "Configuring a Telephone Tool Through a Scripting Language," beginning on page 1-46 for information about TELSetConfig and TELGetConfig.

Opening a Telephone Terminal
Once you've successfully performed the tasks described in the previous sections, you can call TELOpenTerm to open the telephone terminal associated with the tool you've found and configured, as follows:
myErr = TELOpenTerm(myTelRec);
You need to open a terminal before you can call any Telephone Manager functions that manipulate terminals, directory numbers, or call appearances.

Note
You do not need to open a terminal in order to install application-defined message handlers. See the chapter "Telephone Manager Messages" later in this book for information about message handlers.
